4 x DDR5, Maximum Memory Capacity 256GB, Max Memory Support 7800+ OC MHz
Storage
2 x M.2 PCIe 5.0 x 4 slot
2 x M.2 PCIe 4.0 x 4 slot
6 x SATA 6Gb
USB Ports On Board
1 x USB 10Gbps Type-C Port
1 x USB 20Gbps Type-C Port
6 x USB 10Gbps Type-A Port
3 x USB 2.0 Type-A Port
LAN
1 x Realtek RTL8125BG 2.5Gbps LAN Port
Audio
Realtek ALC4080 Codec
7.1 Channel High Definition Audio
Support S/PDIF Output
Back Panel Connectors
1 x HDMI Port
1 x DisplayPort
1 x USB 10Gbps Type-C Port
1 x USB 20Gbps Type-C Port
6 x USB 10Gbps Type-A Port
3 x USB 2.0 Type-A Port
1 x RJ-45 LAN Port
2 x WiFi/Bluetooth Antenna Connector
1 x Flash BIOS Button
1 x Clear CMOS Button
1 x Smart Button
1 x Optical S/PDIF-Out
1 x Mic In
1 x Audio Line Out
1 x Audio Line Out
1 x RS-Out
1 x CS-Out
Internal I/O Connector
1 x Power Connector(ATX_PWR)
2 x Power Connector(CPU_PWR)
1 x CPU Fan
1 x Pump Fan
5 x System Fan
2 x Front Panel (JFP)
1 x Chassis Intrusion (JCI)
1 x Front Audio (JAUD)
1 x Thermal Sensor connectors(T_SEN)
1 x Tuning Controller connector(JDASH)
2 x Addressable V2 RGB LED connector (JARGB_V2)
1 x RGB LED connector(JRGB)
1 x TPM pin header(Support TPM 2.0)
4 x USB 2.0 ports
4 x USB 5Gbps Type A ports
1 x USB 10Gbps Type C ports
