1x USB 3.2 Gen2 Type-C
1x USB 3.2 Gen2 Type-A (Red)
4x USB 2.0/1.1 Type-A
4x USB 3.2 Gen1 Type-A
LAN
1 x RJ 45 Port (Realtek 2.5GbE LAN chip)
Audio
2 x Audio Jacks (1 x Mic, 1 x Line Out)
Realtek Audio CODEC, 2/4/5.1/7.1-Channel
Back Panel Connectors
1 x USB 3.2 Gen2 Type-C port
1 x USB 3.2 Gen2 Type-A port (Red)
4 x USB 3.2 Gen1 Type-A port
4 x USB 2.0/1.1 Type-A port
2 x SMA antenna connectors (2T2R)
1 x Optical S/PDIF Out connector
1 x DisplayPort
1 x RJ-45 port
1 x HDMI Port
1 x Audio Mic in
1 x Audio Line Out
Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
1 x CPU fan header
1 x Front panel header
1 x Front panel audio header
1 x CPU fan/water cooling pump header
3 x System fan headers
1 x System fan/water cooling pump header
2 x Addressable LED strip headers
2 x RGB LED strip headers
3 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x USB Type-C header, with USB 3.2 Gen2 support
1 x USB 3.2 Gen1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x Reset button
1 x Q-Flash Plus button
1 x Reset jumper
1 x Clear CMOS jumper
